382系列為TR5延時型保險絲，額定電壓250V，分?jǐn)嗄芰Π凑誌EC 60127 - 3的要求設計。
功能與特色: 無鉛，100A分?jǐn)嗄芰Γ?降低對PCB板的空間要求， 可直接軟焊或插入，獲國際認證
低內阻，防電擊外殼， 抗振，無鹵素。
| Model | Rated Current | Amp Code | Voltage Rating | Bearking Capacity | Nominal Cold Resistance (Ohms) | Voltage Drop 1.0×1N max. (mV) | Power Dissipation 1.5×1N max. (mW) | Meiting Integral 10×1N min(A2s) |
| 3920280 | 280mA | 0280 | 250V | 35A/250VAC 130A/250VAC | 0.33 | 115 | 168 | 0.048 |
| 3920500 | 500mA | 0500 | 0.163 | 105 | 125 | 2.175 | ||
| 3920800 | 800mA | 0800 | 0.096 | 110 | 280 | 5.120 | ||
| 3921100 | 1.00A | 1100 | 0.0715 | 115 | 400 | 8.00 | ||
| 3921125 | 1.25A | 1125 | 0.0569 | 100 | 500 | 11.95 | ||
| 3921160 | 1.60A | 1160 | 0.04 | 95 | 600 | 18.43 | ||
| 3921200 | 2.00A | 1200 | 0.0298 | 90 | 700 | 29.00 | ||
| 3921250 | 2.50A | 1250 | 0.024 | 85 | 750 | 47.81 | ||
| 3921315 | 3.15A | 1315 | 0.017 | 80 | 1100 | 78.39 | ||
| 3921400 | 4.00A | 1400 | 40A/250VAC 50A/250VAC | 0.0128 | 75 | 1200 | 126.40 | |
| 3921500 | 5.00A | 1500 | 50A/250VAC | 0.0101 | 70 | 1000 | 106.25 | |
| 3921630 | 6.30A | 1630 | 63A/250VAC | 0.0077 | 65 | 1200 | 160.74 |
Littelfuse_392規格書
